IC: AM466320055
Certifications & Approbations
Dimensions (W x H x D) | 83 x 83 (67 x 67) x 21 mm / 3.27 x 3.27 (2.64 x 2.64) x 0.83 in |
Cutting Hole | 70 … 73 mm / 2.76 .. 2.87 in |
Material / Color | ABS / White |
Wire Gauge | 0.2 … 1.3 mm2 |
Stripping Length | 7 … 9 mm / 0.28 … 0.35 in |
Certificates | CE, UKCA, DALI-2, RoHS |
Electrical information | |
Power Supply | DALI Bus |
Max. DALI Current Draw | 6 mA |
Control | DALI |
Marking Terminals | DA, DA |
Motion Detection Indicator | Red (motion detection) |
DALI Indicator | Green (DALI) |
Sensing | |
Motion Detection (62386 – 303) |
PIR sensor |
Light Sensor (62386 – 304) |
Event: 0 … 1000 Lux (10 bit), resolution: 10 Lux |
Mounting Height | recommended height: 2.5 m / 8.2 ft |
Detection Angle | 130 ° |
Function | Configurable |
Environment | |
Operating Temperature Range | 0 … 40 °C / 32 .. 104 °F indoor use only |
Operating Humidity | 0 … 95% (non condensing) |
Storage Temperature Range | -20 … 70 °C / -4 … 158 °F |
Storage Humidity | 15 … 90% (non condensing) |
