SYMPL Fusion

LED Behavior & Device Feedback

Base device

Error-LED: short-short-long

What does it mean

Test mode is active.

The SYMPL dmx Node provides a Test mode for the connected DMX devices. There are two kinds:

using the Identify button and
using the web interface of the SYMPL dmx Node.

The Test mode is indicated by flickering DMX/RDM LED(s) and the blinking Test / Error LED.

How to react

Exit the Test mode

Exit the Test mode and return to the original fixture content:

by double-pressing the Identify button or
by leaving the Test mode page in the web interface, e.g. go to “Dashboard”.

Change the Test pattern

Single-press the Identify button to switch between the Test patterns.
