| Dimensions (W x H x D) |
80 x 160 x 30 mm / 3.15 x 6.30 x 1.18 inch |
| Weight |
188 g / 0.41 lb |
| Power Supply |
PoE Standard IEEE 802.3af, polarity-independent
or 12 … 24 V DC SELV |
| Power Consumption |
typ. 4.5 W
max. 6 W (all LEDs 100% white),
on device plug
|
| Operating Temperature |
0 … 35 °C / 32 … 95 °F |
| Storage Temperature |
0 … 50 °C / 32 … 122 °F |
| Operating/Storage Humidity |
0 … 80% RH, non-condensing |
| Protection Class |
IP20 |
| Installation |
Indoor installation only,
Intra building connections only
|
| Housing |
PC/ABS, glass |
| Mounting |
Wall mount housing, suitable for most international in-wall mounted boxes |
| Certification |
CE, ETL, FCC, UKCA |
| Real Time Clock |
With capacitor backup, holds time for ~1h |
| User Interfaces (UI) |
12 x capacitive touch key
1 x jog wheel with switch |
| System Interfaces |
3 x DIP switch
1 x Ethernet 100 Mbps on device plug, max. cable length: 65 m, for synchronization of multiple devices only
1 x USB 2.0 micro USB-B, for update only |
| DMX Outputs |
2 x DMX512 output, on device plug |
| Fixture Types |
Monochrome (1 channel)
Dynamic White (2 channels)
RGB (3 channels)
RGBW (4 channels) |
| Low-side Switches |
2 x 24 V DC, max. 3 A, ON resistance 50 mΩ, normally open, galvanically isolated, overload protected, on device plug |
| Digital Dry Contacts |
2 x inputs, 5 v DC contact supply, on device plug,
Input high threshold voltage: 2.5 V
Input low threshold voltage: 1.2 V
Typ. input threshold voltage: 1.5 V
Input voltage max.: 15 V
|
| Digital Inputs Supply |
For dry contacts
Use 5 V DC from device (pin 7)
max. 15 mA
Typ. current when sourcing all 2 ports: 12 mA
|
| Device Plugs |
Push-in spring connection plug,
Stripping length: 6mm
Major diameter of isolated cable max. 2 mm
Cable cross-section: solid 0.14 … 0.5 sqmm, flexible 0.2 … 0.5 sqmm
|
| WiFi |
RF frequencies: 2.4 … 2.473 GHz. IEEE 802.11 b/g/n
|
| Sensors |
Proximity sensors for UI activation |
