| Dimensions (W x H x D) |
170 x 59 x 29 mm / 6.69 x 2.33 x 1.14 in |
| Weight |
100 g |
| Power input |
100 … 240 V AC (2-pin terminal) |
| Max. input current at “power input” |
2.5 A |
| Operating temperature |
-40 … 85 °C / -40 … 185 °F |
| Storage temperature |
5 … 95% RH, non-condensing |
| Operation / storage humidity |
5 … 95% RH, non-condensing |
| Mounting |
with key holes on any stable vertical surface |
| Protection class |
IP20 |
| Input |
1 x DALI |
| Certificates |
CE, UKCA, RoHS
|
| Input |
1x DALI
|
| Outputs |
1 x DALI
2 x AC channel:
2 x 100 … 240 V AC,
2 x 1.2 A,
2 x 120 … 288 W
|
| Output dimming curve gamma |
Logarithmic |
| User interfaces |
3 x button, display
|
| Connection type |
Screw terminal connectors
|
| Wire size solid core, stranded wire with end ferrule |
0.5 … 2.5 mm²
(AWG20 … AWG13)
|
| Stripping length |
6 …7 mm / 0.24 … 0.28 in
|
| Tightening / release of wire |
Screw mechanism
|
